Overview of the Programmable R-axis on Automec Backgauge Controls

Backguage Programmable R-axis: Electric disk brakes hold the gauge bar at the proper height once the R-axis moves to position. Includes the motor, amplifier and encoder. 8 precision ball -bushing assemblies are used to traverse the gauge bar up and down.

PC 800 CNC Backgauge Controls for Press Brakes

Automec’s PC800 is a graphical backgauge control for its family of CNC backgauges that uses digital photos and 2-D graphics to make your press brake forming easier.
